Motion Control – Motorized Rotary Stage, the AR39-AH Available from OES!

Motion Control – Motorized Rotary Stage!
motion control - miniature rotary table

motion control - OES Components







Van Nuys, CA —– Motion Control – Rotary Stages – A rotary stage is a component of a motion system used to restrict an object to a single axis of rotation. The terms rotary table or rotation stage are often used interchangeably with rotary stage. Our rotary stages provide accurate positioning performance in a low profile and compact footprint. They are perfect for the limitations and requirements of the laboratory and are also used in manufacturing environments. These stages are ideal for optics, measurement, alignment and other demanding applications.

Motion Control – Miniature Voice Coil Stage features 1 Micron Repeatability!

Motion Control – Miniature Voice Coil Stage!

motion control - miniature voice coil stage




motion control - miniature components





Forestville, CA, — Motion Control – This VCS-10V Voice Coil Stage: 10mm of linear motion; Ball bearing guidance system; 1 micron position repeatability; 40 G’s acceleration; Non-contact electro-optic position sensor; Kinematic load mount; Direct SCA814 Servo Controlled Amplifier compatibility; 33 x 36 x 76mm, 230 grams

Motion Control – ServoStep Integrated Stepper Motor in size NEMA 17, torque up to 0.8 Nm!

Motion Control Integrated Step Motors

motion control integrated stepper motor

Vaughan, Ontario, Canada — Motion Control Components — JVL Industri Elektronik A/S, one of the world leaders in the field of integrated servo – and stepper motors introduces a new compact and slim stepper motor. The new ServoStep integrated stepper motor series MIS171 to MIS176 have a NEMA 17 42×42 mm flange and include controller with 6 different industrial Ethernet protocols, absolute multiturn encoder, closed loop and M12 connectors. This new motor family is based on the latest microprocessor and cooling technology and an advancement compared to previous designs.

motion control - electromate robotics

All the necessary electronics in a stepper system are integrated in the motor itself and are similar to the concept used by other JVL motors, making it very easy to use in all kind of motion control stepper or servomotor applications.

Motion Control- Application – Underwater inspection on twelve wheels.

Motion Control – Application – Underwater Inspection

Motion Control – Application – Inspecting flooded pipes of power plants requires skilled, high-precision handling. And the robotic vehicles have to be optimized accordingly, for example to dive 20 m deep. The new seawater manipulator is capable of maneuvering underwater in pipes, where it can be used to perform inspections. RE motors by maxon are responsible for the dynamic drive of the robot.

motion control - application

motion control - maxon motor





Taunton, MA — Motion Control Application – In robotics, manipulators are those devices that enable physical interaction with their surroundings. For this interaction, the robotic vehicles are equipped with appropriate tools, gripper systems or measuring devices. In the case of the seawater manipulator, this equipment largely consists of high-performance cameras used for pipe inspection. Ibass, from Augsburg in Germany, develops, manufactures and distributes manipulators for various in-pipe applications: inspection, grinding, welding, retrieval or suction.

Motion Control – Get Zero Cogging and High Throughput from Low Cost Moticont Linear Actuators!

Motion Control – Electric Cylinder!

motion control - electric cylinder


motion control - moticint



Van Nuys, CA — motion control – Moticont has introduced their highest force linear actuator in their DDLM Linear Actuator Series. The DDLM-038-051-01Linear Actuator is a low cost non-commutated linear actuator that is easily integrated into new and existing applications, and is the ideal choice when upgrading from a pneumatic system. Compact, clean, and quiet, this fully enclosed linear actuator, also referred to as an electric cylinder, is 1.500 in. (38.1 mm) in diameter with a housing length of 2.00 in. (50.4 mm) long.

Motion Control – Linear Bearings – Which Type is Right for Your Application?

Motion Control – Linear Bearings – Comparison: Ceramic Coated vs Linear Ball Bearings

LM76-Difference-01







LM76-Difference-02

Motion Control – Linear Focus Actuator from Equipment Solutions Features 200 Nano Meters Repeatability!

motion control - linear focus actuator


motion control - miniature components



Forestville, CA, – — Motion Control – This LFA-0604 Linear Focus Actuator: Flexure guidance system, 6 millimeter clear aperture, 4 millimeters of linear motion, 90 G’s acceleration (no load), 200 nanometers positioning repeatability, non-contact electro-optic position sensor, direct SCA814 Servo Controlled Amplifier compatibility, 38mm x 24mm, 80 grams

Motion Control – High Precision XYR Alignment Stage Has Better Than +/- 3 Micron Accuracy!

Motion Control – Alignment Stage!

motion control - alignment stage
Van Nuys, CA – — Motion Control -Optimal Engineering Systems, Inc. (OES) has introduced the XYR-300-400 Alignment Stage offering +/- 3 micron accuracy for industrial, medical, semiconductor, production, research, and laboratory applications.  The XYR-300-400 Alignment Stage features +/- 15 mm of travel in the X and Y axes and +/- 5 degrees of rotation (theta). It moves in XY-plane and rotates around the center of the XY-plane.

motion control - stages - custom

The XYR-300-400 Alignment Stage feature linear resolutions of the X and Y axis of 1 micron resolution with a 10 micro-steps per step motor driver and static parallelism of less than 0.05 mm.

Motion Control – Maxon’s Driven Magazine – See the article “Speed or Torque – or Both?”

Motion Control – Maxon’s Driven Magazine

motion control driven magazine



Motion Control article “Speed or Torque – or Both” in Maxon’s Driven magazine helps in selecting the right motor for an application.  An application that could be on Mars, under water, or even implanted in the human body!

motion control - maxon





Fall River, MA — Motion Control – The Maxon catalog contains a large number of brushless motor types that are called EC Motors. The artice in this issue of DRIVEN briefly describes their properties and possible areas of application.

Motion Control – Don’t Just Settle! Select the “Right” Miniature Linear Voice Coil Motor for the Application!

Motion Control –  Miniature Linear Voice Coil Motor!

motion control- miniature voice coil motor

Van Nuys, CA — Motion Control Components – Moticont has added two miniature linear voice coil motors to its LVCM family of Linear Voice Coil Motors! Sharing the same physical dimensions, each is just 1.000 in. (25.4 mm) in diameter and the housings are 1.500 in. (38.1 mm) long. As every application is different Moticont offers two motors in the LVCM-025 Series of Voice Coil Motors.

motion control - moticont

The LVCM-025-038-01 features a continuous force of 2.5 lbs (11.0 N) and a peak force of 7.8 lbs (34.7 N) and the LVCM-025-038-02 features a 1.000 in (25.4 mm) stroke, where as, the LVCM-025-038-01 features a stroke of 0.37 in. (9.5 mm) and the LVCM-025-038-02 features a continuous force of 16.4 oz (4.6 N) and a peak force of 51.9 oz (14.4 N).

Motion Control – The Engineering Edge – Jet Rail Linear Roller Blocks – Bearing Specifications and Loading Instructions

Motion Control – the Engineering Edge – Jet Rail
motion control - engineering edge

motion control - jet rail linear bearings

Motion Control – Ultra-High Precision, Compact, Low Cost, Optical Positioning System Features Zero Translation from Equipment Solutions!

Motion Control – Linear Focus Actuator
motion control - linear focus actuator


motion control - miniature components





Sunnyvale, CA, — Motion Control – Optical Positioning System – Developed for precision optical positioning applications the LFA-1210 Linear Focus Actuator features a patented zero-translation tangential flexure for high speed travel. The clear aperture, 10 mm (0.394 in.) stroke length and standard 12 mm optics mount (or an optional DIN mount for use on microscopes) make this linear focus actuator ideal for: Optical focusing, scanning, interferometry, surface structure analysis, disk drive testing, autofocus systems, confocal microscopy, biotechnology, and semiconductor test equipment.

Motion Control – Galil’s RIO-47142 Pocket PLC with Two Ethernet Ports!

Motion Control – Galil Controller


motion control -

motion control - electromate robotics







Vaughan, Ontario – Canada — Motion Control – Galil, an industry leader in motion control technology, is announcing the latest product in their RIO Pocket PLC Series. The new RIO-47142 includes an internal switch with two Ethernet ports for daisy-chaining multiple RIO units. This allows management of an unlimited number of inputs and outputs without an external Ethernet switch.

Motion Control – High Precision Built-to-Order XZR Positioning Stages Available from OES!

Motion Control – Precision Positioning Stages!

motion control XZR Stage
motion control - stage





Van Nuys, CA —– Motion Control – Build-to-Order High Precision XZR Positioning Stages (X-axis, Z-axis, and Rotary- axis) are the newest addition to the OES (Optimal Engineering Systems, Inc.) family of motion control stages.  When specifying an XZR stage a user can select from a combination of linear stages with travel lengths of 15 mm, 30 mm, 50 mm, and 75 mm for the X and Z axes that feature high precision 1 mm per turn lead screws.  For the rotary axis a 60 mm diameter rotary table or 100 mm diameter rotary table are available.

Motion Control – The world’s lightest electric mountain bike features maxon BIKEDRIVE AIR

Motion Control – Application – Mountain Bike

With the new Lightrider E Ultimate, Swiss bicycle manufacturer Thömus is launching the world’s first full-suspension cross-country electric mountain bike weighing less than 15 kilograms. This record-breaking weight is made possible by the small and efficient maxon BIKEDRIVE AIR drive in the extremely lightweight Thömus ultra-high modulus carbon frame.

motion control - lightest mountain bike

Taunton, MA — Motion Control – The partnership between Thömus and drive specialist maxon that began in the winter of 2021 is delivering results not only in World Cup racing. Behind the scenes, a lot of work has been done on a new, ultra-lightweight electric mountain bike in recent months, which, together with the maxon BIKEDRIVE AIR drive, heralds a new era for electric mountain bikes.

motion control - maxon

Weighing less than 15 kilograms in total and with a slim, rigid frame, the Lightrider E Ultimate is a real racing bike that can be maneuvered easily and agilely over any terrain.

Motion Control – Low Inertia, High Precision, Hollow Core Voice Coil Motor from Moticont!

Motion Control – Hollow Core Voice Coil Motor


Van Nuys, CA – Motion Control – A low inertia hollow core voice coil or moving coil linear motor from Moticont, the HVCM-051-025-019-01, features high acceleration, precise positioning to less than one micron (0.00004 in.), high reliability, and low cost. This cleanroom friendly, non-commutated motor is available off-the-shelf. The HVCM-051-025-019-01 hollow core voice coil linear motor has an open apertures of 0.750 in. (19.05 mm).
motion control - moticont

The hollow core allows for optics, illumination, laser beams, or cables to pass through. With a 0.50 in. (12.7 mm) stroke length, a continuous force rating of 4.8 lbs (21.3 N) and a peak force of 15.15 lbs (67.4 N) at a 10% duty cycle, this compact voice coil motor measuring just 2.000 in. (50.8 mm) dia. X 1.00 in. (25.4 mm) housing length, is ideal for applications such as: Positioning, medical diagnostics and testing, laser beam steering, dynamic vibration absorption, optical focusing, laser cutting & welding, scanning, assembly, and wafer handling.

Motion Control – Low Cost, High Accuracy, Straight and Curved Rail & Roller Block Systems!

motion control - roller blocks

motion control - linear bearings



E. Longmeadow, MA – Motion Control – Low cost, SAIBO SB-LGV Straight and Curved Rail & Roller Block Systems are available exclusively from LM76 in three widths, and two styles to meet load requirements up to 7200 N. (1619 lbs). These low profile linear and curved rail systems feature: Low noise, smooth travel, high speed, low weight, high accuracy, sealed radial low friction bearings, low cost, and easy installation into new and existing applications. Long life, SB-LGV Straight and Curved Rail & Roller Block Systems are available in lengths to 2000 mm (79 in.) and curved sections with radiuses from 79.5 mm (3.13 in.) to 516.5 mm (20.3 in.) in 90O, 180O, and 360O sections.

Motion Control – Linear Focus Actuator from Equipment Solutions features 200 Nanometer position Repeatability!

Motion Control – Linear Focus Actuator features 200 Nanometer repeatability!

motion control - linear focus actuator


motion control - miniature components





Forestville, CA, – — Motion Control – This Custom LFA-2003 Linear Focus Actuator Features: 20 millimeter clear aperture, 3 millimeters linear motion, 200 nanometer position repeatability, Flexture guidance system, ‘C’ mount lens adapter, integrated coil temperature sensor, direct SCA814 Servo Controlled Amplifier compatibility, 74mm x 61mm, 690 grams.

Motion Control – Precision Manual XYZ Stage from OES!

Motion Control – Precision Manual XYZ!

motion control - xyz manual Stage
motion control - stage





Van Nuys, CA —– Motion Control – This manual crossed roller XYZ-axis positioning stage is made of aluminum alloy with an black anodized coating. The table size is 25 x 25 mm has a body weight of 0.16 Kgf. The maximum load of this super thin table is 1 Kgf. The movement accuracy is Straightness 5µm ,Vertical yawing 30″ and Parallel yawing 25″.

Motion Control Application – Monitoring Over 6,000 Miles with the Galil DMC-4020 Motion Controller

Motion Control Application – Motion Controllersmotion control - controller Application
motion control - electromate- robotics







Vaughan, Ontario, Canada – Motion Control Application – It’s estimated over 850,000 have entered the United States unlawfully since 2002. The try and prevent this, U.S. Border Patrol agents have the arduous task of monitoring over 6,000 miles of land along the southern US-Mexican and northern US-Canadian borders. To assist in this demanding task, a number of solutions are employed. This includes rangers, canine units, helicopters, drones, ATV’s, watchtowers, and 20-foot tall walls. Even with all these efforts, it’s not enough to cover all those miles.
